WPM FRS / Gen 1 BRZ Roll Bar

Engineered for the first-generation Toyota 86, Scion FRS, and Subaru BRZ (ZN6), this roll bar features a weld-in base plate system similar to the OEM BMW GTS cage design. Base plates are welded to the chassis at the factory side impact beam, providing a true structural connection far superior to rivnut or single-stud mounting methods.

Specifications

• TIG-welded Docol R8 high-strength steel construction
• 1.75″ x .095″ main structure with 1.5″ x .083″ bracing
• Weld-in main hoop base plates for secure chassis mounting
• Pads welded to OEM side impact beam and rear frame rails
• Rear base plates attach to wheel tub and rear shock top hat for maximum rigidity

Compatibility Note

ZN6 and ZN8 half cages are interchangeable. New weld-in plates are available at no cost if switching between generations.

Manufactured by Walker Pro Motorsport — precision-engineered motorsport safety equipment built in the USA.
